This model comes in two flavors – Plastic ABS case and Metal case. The Metal case option supports the RK3399 Processor with PoE. The Plastic ABC case with the RK3399 processor currently does not support PoE.
Additional features include operating in Kiosk Mode, boot into Application, and motion sensor for detecting human presence and turning on / off the screen.
Features
- Main CPU: Rockchip 3399, Cortex A9 Quad-Core,2.4Ghz (optional Metal case RK3399 Hexa-core CPU )
- Display: 15.6″ IPS
- Resolution: 1920*1080 pixels
- RAM: DDR3 2GB (4GB Optional)
- Flash: 8GB (16/32 GB optional )
- OS: Google Android 9.0
- Bluetooth: Yes
- Mini USB OTG / USB Host 2.0
- Camera : Front: 5.0 MP ,
- PoE: 802.3af/at (optional)
- VESA: 100x100mm
- Installation Options: Wall Mount ( Inwall and on the wall ), desk mount:
Case: ABS plastic, Metal Case (optional). - Mounting Options: Surface Mount for ABS and Metal Case. Flush mount option only for ABS case.
Optional
- Kiosk Mode
- Auto-start Application
- Motion Sensor – Turn On when the user is near and turn off the screen when the user is away.
- OEM Logo/Branding
Specifications
| CPU | Hexcore core cortex A9,1.6G,RK3399 | |
| Processor speed 2.4 GHz | ||
| GPU | Quad core Mali 400 | |
| Display | 15.6′ LG IPS Screen 1920*1080 16:9 | |
| Touch panel | Capacitive Touch Panel | |
| RAM | 2GB DDR3 (optional 4GB) | |
| Storage | Built-in 16G Nandflash, External 32GB TFCard | |
| OS | Android 9.0 | |
| Network | Wireless LAN 802.11 b/g/n | |
| Bluetooth 4.0Â | ||
| 10/100 Ethernet RJ45
Supports PoEÂ Â |
||
| 3G (supports external 3G Dongle) | ||
| Audio | Built-in stereo sperker 2*3W | |
| USB | USB Hosts x 3, 1 USB Mini OTG | |
| Camera | 5MP front | |
| HDMI | HDMI 1.4a | |
| Office Software | WORD, EXCEL, POWERPOINT, PDF, TXT | |
| Audio Player | Support 1080P H.264, VP8, RV, WMV, AVS, H.263, MPEG4 | |
| Photo | JPG, BMP, GIF | |
| E-Book | Support | |
| I/O Ports | Mini-USB OTG | 1 |
| USB HOST port | 3 | |
| Earphone jack | 1 | |
| DC Jack | 1 | |
| PoE/RJ45 | 1 | |
| Micro SD card slot | 1 | |
| Power | DC In | |
| In/Output | Input: AC100-240V 50-60Hz | |
| Output: 12V 4A | ||
| Applications | Browser, office software, games, Video Player/Audio Player | |
| Skype video chat, MSN, Email, Caculator, Calendar etc | ||
| Audio/Video/Game | Support AVI, RM, RMVB, MKV, WMV, MOV | |
| Support 1080P full HD movie-play | ||
| Support different 3D games | ||
| Dimension | 242.9*189.8*9mm | |
| Case | Plastic ABS or optional Metal Case | |
| Accessories | High speed USB 2.0 cable | |
| User manual | ||
| Wall charger (100-240V 50-60Hz 5V 2A) | ||
| USB adaptor | ||
