10″ Android Panel PC with front NFC and PoE

$445.00

The GK-HD-A1001PNFC Android Panel PC with built-in front NFC Reader is widely used in several applications requiring NFC such as time & attendance management, access control, and meeting room management. The unit supports a front built-in NFC reader that supports industry-standard 13.56MHz frequency and optional 1.25Khz frequency. A key feature of the NFC support is that unit uses native Android NFC APIs which makes it easy to directly support many of the NFC-based applications that are already available in the market.

Compare
Add to wishlist
SKU: GK-HD-A1001PNFC Categories: ,
Description

Another key feature of the display is the support for multi-colored LED status lights that can be programmatically controlled. The LED lights can be tied to an NFC reader or any other event. For example, so you can set the LED color to RED when a room has been reserved and a meeting is in progress.

The display supports PoE ( Power over Ethernet) that allows you to feed both power and data through a CAT5 cable and directly connect to the PoE switch. There is no need for any PoE splitter solution thereby lowering your costs of installation, deployment, and maintenance.

The unit can be built with various options including display screen sizes of 10.1″ and 15″.

Key Features

  • Display: 10.1″ Capacitive touch screen 1280×800 ( other screen sizes can be customized).
  • NFC R/W: 1.36MHz.
  • Optional Bluetooth 4.0.
  • Vesa Mounting: 100×100.
  • LED Status lights

Advanced Feature (Custom):

  • Branding & customization.
  • Pre-loaded apps.
System Specifications
CPU ARM Cortex-A7 A20 1GHz Dual Core, Mali400mp2 GPU. RK3288 Chipset.
OS Android 5.1 / 6.0
Memory 2G ram DDR3
Storage 8GB SD/SDHC
Display 10.1 inch Capacitive Multi-touch IPS screen,1200*800 Pixels;300cd/m2

Optional (15 Inch)
Display Resolution 1280×800 16:10 Aspect ratio
Display Brightness 300nits
 LED Status lights  LED status lights on the left and right side of the unit.

Programmable to multiple colors, RED, Green, Blue.
Communication Wi-Fi IEEE 802.11 b/g/n
Bluetooth Bluetooth 4.0 (A2DP+EDR)  Optional
Proximity Wireless
 NFC ( built-in) NXP544 chipset
 Front placement
Camera Dual Camera: Front 2.0M camera, Back 8.0M Camera;
I/O Interface
2 x USB 2.0 type A
1x RJ45 (PoE)
1x VGA, 1 x HDMI

Mechanical & Environment
Dimensions / Weight Dimention: 262*172*24.5mm, Net weight:about 520g
Certifications CE, FCC, UL 60950-1
Operating Temperature -20°C to +60°C (MIL-STD-810G Method 501.5 and 502.5)
Storage Temperature -30°C to +70°C (MIL-STD-810G Method 501.5 and 502.5)
Humidity 5-95% without condensation (MIL-STD-810G Method 507.5)
Power Management
Power Adapter 6-36V DC, 8W
